Phi lips IU22 DSC Board
1.P/N: 453561233804/453561233805
2.Pre-owned original one ,in excellent condition
3.We provide 60 days warranty
Various GE/Siemens/Toshiba/Hitachi/ Biosound/Medison Ultrasonic Boards are within our Repair/ Maintenance range.
Other ultrasound parts related that we can offer:
| Brand | Machine type | Part type | Part number |
| Phil ips | CX50 | Mainboard | 453561368033/453561622163/453561495832/453561239048 |
| CX50 | Channel board | 453561473231/453561239066/ 453561662431 |
| CX50 | Power Supply board | 453561375144/453561384831/453561473243/453561473241 |
| Affiniti 50/Affiniti 70 | ACQ acquisition control board | 4535161610416/4535161610426 |
| EPIQ 5/EPIQ 7 | ACQ Acquisition Module board | 453561734844 /453561738042/453561921813/453561798362/453561704244/453561704245 |
| iU22/iE33 | CB Board (Channel Board) | 453561156011/453561156012/453561156014/453561164271/453561287451/453561303902 |
| iU22/iE33 | AIM Board | 453561210241/453561210243/453561160672/453561210243 |
| iU22/iE33 | FEC (Front End Controller) | 453561278261/453561278266/453561464291/453561153751 |
| iU22/iE33 | EMB (excelsior motherboard) | 453561419431/453561382231/453561419431 |
| iU22/iE33 | UMB (Unified Motherboard) | 453561254492/453561360251/453561244586/453561604293 |
| HD7/Envisor | T/R board | 453561448371 |
| Envisor | Contral board | 453561184013 |
| Envisor | TR board | M2540-20240/453561448371 |
| Envisor | RX/TX | M2540-20040 |
| Envisor | APIO | 453561235651 |
Knowledge Point
About PHI LIPS IU22 DSC Board
1. The role of DSC Board in IU22 system
DSC board (Data Split Channel) plays a vital role in IU22 ultrasound diagnosis system. It is mainly responsible for receiving radio frequency (RF) data from front-end controller (FEC) and performing standardized processing. These processed data are then sent to the PCI bus of the computer through dual data stream splitting for further processing. DSC board also undertakes a series of important ultrasound processing tasks, such as dynamic range control, contrast enhancement, echo detection, automatic gain control (AGC) and time gain compensation (TGC).
2. Technical features of DSC Board
Data processing capability: DSC board has powerful data processing capability and can process a large amount of ultrasound data in real time to ensure image quality and diagnostic accuracy.
Standardization processing: Standardize the received RF data to provide a unified data format for subsequent image processing and display.
Versatility: In addition to data processing, DSC board also participates in multiple ultrasound processing tasks of the system, improving the overall performance and stability of the system.
3. Overall architecture of IU22 system
The IU22 ultrasound diagnostic system is a highly integrated system, and its hardware structure can be roughly divided into five parts: front end (transmission and reception of ultrasound), computing and processing, display, control and power supply. As an important part of the computing and processing part, the DSC board works with other hardware components to achieve high-quality ultrasound imaging and diagnostic functions.
4. Maintenance and care of DSC Board
Although the DSC board is a key component in the ultrasound diagnostic system, its maintenance and care should still be paid attention to in daily use. This includes regular cleaning of the system, checking the connection of each component, and ensuring that the system is in a suitable working environment. In addition, the repair and replacement of key components such as the DSC board should be performed by professionally trained technicians to ensure the normal operation of the system and the safety of patients.
We provide professional ultrasonic plate repair services.10+years of professional maintenance service team.
If you need any product, please feel free to contact us.
Various Ultrasound Systems that we served
| GE Ultrasound System |
| LOGIQ P5, LOGIQ P6, LOGIQ S7, LOGIQ S8, VOLUSON 730, VOLUSON S8, VOLUSON P8, VOLUSON S6, VOLUSON S20, VOLUSON P8, VOLUSON E10, VIVID E9, LOGIQ BOOK, LOGIQ 5, LOGIQ 7, LOGIQ 9, LOGIQ E9, LOGIQ F6, LOGIQ F8, VIVID I, VIVID Q, VOLUSON I, VOLUSON E, VIVID S5, VIVID 3, VIVID 7... |
| Hitachi-Aloka Ultrasound System |
| F31, F37, SSD-3500, SSD-3500, SSD-4000, SSD-5000, ALPHA 5, ALPHA 6, ALPHA 7, ALPHA 10, PROSOUND F75, HI VISION AVIUS, HI VISION PREIRUS, EUB-5500, EUB-6500, EUB-7500, EUB-8500, Arietta 60, Arietta 70, Ascendus... |
| Siemens Ultrasound System |
S2000,S3000,SC2000,X300,P500,OXana,Juniper,Omini...
|
Product Tags:
|
|
453561233804/453561233805 DSC Board Phil ips IU22 Ultrasound System Images
|
